Usually the lower part of the signal power is not used for DTMF digit generation as this can become sensitive to various disturbances and losses. Several specifications for DTMF tone parameters are given in Q.24 and listed in Table 7.2.Īs listed in Table 7.2, DTMF digit tones have a higher dynamic range in power levels, but the generation operates at nominal power levels of -12 to -3 dBm. To avoid making multiple detections of the same digit, PSTN or VoIP gateways decide on the digit after completion of a long duration tone.
When the digit key is held down continuously, most phones generate a continuous DTMF tone. A DTMF tone is generated as a combination of two frequencies as per Table 7.1. This process typically occurs within 16 to 100 ms of when the button is pressed and needs to be debouched by the microprocessor so that it is not viewed as multiple button presses.ĭTMF tones are sent on the phone line TIP-RING interface.
When a mechanical switch is pressed, it typically “bounces,” which generates a series of open and closed states before settling to the final state. Almost all modern telephones have a set of mechanical switches (often arranged as a 4 x 4 matrix) interfaced to a microcontroller that scans and debounces these contact closures however, the microcontroller will have many other functions in addition to DTMF. DTMF functional representations in the VoIP Adapter. Values of Multifrequency Push Button Receiving Parameters for Multiple Administrations from ITU-T-Q.24įigure 7.1. FXO interfaces also generate or accept DTMF Table 7.2. 7.1, the foreign exchange office (FXO) is equivalent to the telephone resident inside the VoIP gateway. The foreign exchange subscriber (FXS) interface on the VoIP adapter also generates DTMF tones to the telephone during DTMF caller ID and call waiting caller ID.
Telephones generate DTMF tones, and these tones reach the PSTN local switch or VoIP gateway in the microphone path.
